LONG: 8.78 in. x 2.95 in./3.94 in. x 1.22 in./1.65 in.
(223 mm x 75/100 mm x 31/42 mm)
SHORT: 7.87 in. x 2.95 in./3.94 in. x 1.22 in./1.65 in.
(200 mm x 75/100 mm x 31/42 mm)
Weight
Short: 16.2 oz./461 g; Long: 18.6 oz./526 g
Keyboard
Alpha Numeric (long models)
QWERTY or Numeric (short models)
High reliability keypad ultra-white backlight
Camera
Optional color, 8 MP, autofocus, 4X digital zoom, Bright LED flash,
video capable
Power
PowerPrecision Li-Ion batteries
Two options: High Capacity 4400 mAh or Standard Capacity 2760
mAh
Display
3.7 in. VGA/QVGA (640x480)
Transflective color; touch display
Sunlight visibility with 240 cd/m² brightness
LF Module
Frequency: 125 kHz
Protocols supported: EM 4x02; EM 4x05;
EM 4x50; EM 4200; Q5; Hitag 1 & 2; Hitag S
UHF Module4
Frequency: 868 MHz or 915 MHz
Protocols supported: EPC Class 1 Gen 2;
ISO 18000-6C
HF Module
Frequency: 13.56 MHz
Protocols supported: ISO14443 type A, B and C, ISO 15693; NFC
“Reader to Tag” Mode; full Mifare support
Data encryption: 2 SAM slots; ID1 SAM format; Class A, B and C
Bluetooth
Integrated Bluetooth V2.0+EDR
Bluetooth coexistence (v2.1 available Q2 2014)
GPS
Optional GPS/Wi-Fi diversity antenna module (supports AGPS and
SBAS)
Operating
Temp
-20°C to +50°C (-4°F to +122°F)
Storage Temp
-40°C to +60°C (-40°F to +140°F)
Humidity
5% to 95% non-condensing
IP Sealing
IP65, IEC 60529
Drop Specs
1.5 m (5 ft.), 26 drops to polished concrete (powered with options
and accessories);
multiple 1.8 m (6 ft.) drops to polished concrete
